1. DC 24V Power Input (5.08 PITCH)

2. Reverse Polarity Protection for Power Supply

3. 32 INPUT:

   1) 2-wire input type INPUT, maximum 10mA current drive

   2) 3-wire input type INPUT, current provided by external power supply

   3) Single-point ESD protection for INPUT

   4) INPUT response time <2KHz

   5) Supports NPN/PNP switching

4. 32 OUTPUT:

   1) Optical isolation, FET output

   2) Single-point maximum 1A continuous output

   3) Supports inductive load

5. Detachable European 5.08 PITCH Terminal Block

6. 40-PIN Horn-shaped Socket, Anti-Mistake Design
