1. DC24V Power Input (5.08 PITCH)

2. Provides reverse polarity protection

3. 32 INPUT

   1) 2-wire input type, maximum 10mA current drive

   2) 3-wire input type, current provided by external power source

   3) Single-point ESD protection for input

   4) Input response time <2KHz

   5) Supports NPN/PNP switching

4. 32 OUTPUT

   1) FET output

   2) Provides a maximum continuous output of 2A per point

   3) Total 32 points, providing a continuous output of 16A

   4) Supports inductive load

5. SPI full-duplex bus communication

6. Supports CRC check

7. Detachable European standard 5.08 PITCH terminal block

8. Input (8PIN) / Output (4PIN) foolproof design
