1. DC 24V Power Input (5.08 PITCH)

2. Reverse Polarity Protection for Power Supply

3. 32 INPUT

   1) 2-wire input type INPUT, provides a maximum of 10mA current drive.

   2) 3-wire input type INPUT, current supplied by external power source.

   3) INPUT provides single-point ESD protection.

   4) INPUT response time < 2KHz.

   5) Supports NPN/PNP switching.

4. 32 OUTPUT

   1) Optocoupler isolation, FET output.

   2) Provides a maximum of 2A continuous output per point.

   3) Supports inductive loads.

5. Detachable European 5.08 PITCH Terminal Block

6. INPUT (8PIN)/OUTPUT (4PIN) Anti-error Design
