1. DC 24V Power Input (5.08 PITCH)

2. Reverse Polarity Protection for Power Supply

3. 24 INPUT

   1) 2-wire input type INPUT, provides a maximum of 10mA current drive.

   2) 3-wire input type INPUT, current supplied by external power source.

   3) Provides single-point ESD protection.

   4) INPUT response time < 2KHz.

   5) Supports NPN/PNP switching.

4. 16 OUTPUT

   1) FET output.

   2) Provides a maximum of 2A continuous output per point.

   3) Supports inductive loads.

5. 2-Axis General-purpose Axial Control

   1) Differential pulse control (up to 4MHz).

   2) Analog speed closed-loop control (12 BIT -10V~+10V).

   3) Differential encoder feedback input (up to 4MHz).

   4) 12 BIT -10V~+10V DAC output.

   5) 12 BIT -10V~+10V ADC input.

   6) Supports PWM output.

   7) Supports SSI encoder input.

   8) Input/Output

      A. 2 INPUT

         1) 2-wire input type INPUT, provides a maximum of 10mA current drive.

         2) 3-wire input type INPUT, current supplied by external power source.

         3) Provides single-point ESD protection.

      B. 2 OUTPUT

         1) FET output.

         2) Provides a maximum of 100mA continuous output per point.

         3) Supports inductive loads.

6. Supports DC Clock Synchronization

7. Detachable European 5.08 PITCH Terminal Block

8. INPUT (8PIN)/OUTPUT (4PIN) Anti-error Design
