1. DC24V Control Power Input (5.08 PITCH), DC48V Strobe Power Input (5.08 PITCH)

2. Provides Reverse Polarity Protection

3. 2-Channel Light Source Control

   1) PWM Pulse Width Modulation, Duty Cycle 0~100.0%, Adjustment Accuracy 0.1%

   2) PWM Frequency Adjustable, Range 1K~63KHz

   3) DC24V Light Source Voltage Output

4. 2-Channel Strobe Control

   1) Strobe Pulse Width Output Adjustable, Range 0~1023us

   2) Supports 2 Isolated Camera Trigger Output Control Points

   3) Supports 2 Isolated External Strobe Input Trigger Control Points

   4) Supports Time Phase Adjustment Between External Strobe Input Trigger and Camera Trigger Output Control Points, Adjustment Range 0~32767us

5. 8 INPUT

   1) 2-Wire Input Type, Maximum 10mA Current Drive

   2) 3-Wire Input Type, Current Supplied by External Power

   3) Provides Single-Point ESD Protection

   4) Input Response Time < 2KHz

   5) Supports NPN/PNP Switching

6. 8 OUTPUT

   1) FET Output

   2) Provides Single-Point Maximum 2A Continuous Output

   3) Supports Inductive Loads

7. Supports DC Clock Synchronization

8. Detachable European-Style 5.08 PITCH Terminal Block
