Product Introduction

1. Integrated all-in-one design: lightweight, reliable, and cost-effective.

2. Smooth MISS point trajectory: optimizes machine movement at MISS points, ensuring smoother operation, reducing machine impact, extending service life, and improving efficiency.

3. Torque detection and protection: real-time torque protection safeguards robotic arms and machines; detects torque during product handling to protect machine grippers from excessive pressure; collision protection during processing to prevent damage.

4. Compatible with standard CNC MACRO calculations, with developed instruction and decimal point redefinition, facilitating easier customization for non-standard motion.

Hardware Introduction

1. Input interfaces: receive signals from external devices such as machine panel buttons, sensors (position, temperature, etc.), and external CNC programs. Common interfaces include USB and Ethernet, enabling flexible device connection and data transfer.

2. Output interfaces: output processed control signals to machine actuators like motors, solenoid valves, indicator lights, controlling machine movement, actions, and status display. Signal types must match connected devices to ensure accurate transmission and execution.

3. Equipped with a 7-inch touchscreen for displaying CNC operation interface, machining programs, parameters, machine status, and alarms, facilitating operator monitoring and control.

4. Communication capability with external devices, such as data transmission with upper computers (e.g., PCs) for remote monitoring, program transfer, system upgrades; or networking with other CNC devices for coordinated multi-machine operation and centralized management.

5. High-resolution color display for clearer visuals.

6. Supports ultra-long power-off data retention for reliable real-time user data recording.

7. Uses high-performance CPU as the CNC system core processor, handling various CNC instructions, programs, and computations with fast response and high efficiency.

8. USB 3.0 interface for faster program transfer and import.

Software (Function) Introduction

1. RT-Linux embedded control system platform.

2. Fully compiled execution modules.

3. Configurable IoT development platform.

4. Remote fault diagnosis and upgrade assistance.

5. Platform-based design philosophy.

6. 64-bit high-speed, high-precision contour control.

7. Dialog-based auxiliary program editing.

8. Special curve machining: supports parabolic and spline curves with constant linear speed machining for smoother surface finish; spline teaching function fits curves between points automatically with cubic equations, smoother than traditional teaching.

9. Supports one-to-one gantry, vertical multi-joint robots, and SACRA robots.

10. Supports non-standard pallets and customized pallet modules.

11. Torque detection and protection: real-time torque protection safeguards robotic arms and machines; detects torque during product handling to protect grippers from excessive pressure; collision protection during machining to prevent damage.

12. Built-in standard instruction set dialog programming module, easy operation, program positions linked with points, one-key position adjustment.
